KeyPad Outdoor Jeweller

KeyPad Outdoor Jeweller

Wireless keypad supporting authentication via Pass, Tag, smartphones, and codes. For outdoor and indoor use.

Coming soon

IN PROGRESS

Control your space, rain or shine

KeyPad Outdoor Jeweller is the first wireless Ajax keypad for managing security and automation outdoors. With multiple authentication methods, the device ensures convenient and secure system control in any scenario. A solid radio communication range and pre-installed batteries make the device ideal for hard-to-wire site and off-grid locations. The sturdy enclosure with large mechanical buttons is built to withstand extreme weather and physical impact. Clear sound and LED indication provide intuitive feedback, enhancing the overall user experience.

Discover KeyPad Outdoor Jeweller

Wireless keypad supporting authentication via Pass, Tag, smartphones, and codes. For outdoor and indoor use.

Watch on Youtube

Key features

Pass and Tag

Support for contactless access devices

Pass cards and Tag key fobs featuring DESFire® technology

Control via smartphone

using Bluetooth Low Energy (BLE)

Two operating modes

Security

Automation

easy mode switching with a long press of the OK button

Bypass mode

entry delay to confirm a security mode change

Duress codes

for cases when a user is forced to disarm the system

Passcode

Four types of access codes

Keypad code

User codes

Unregistered user codes

RRU codes

Built-in panic button

Built-in panic button

Large mechanical buttons

sleek feedback even if a user is wearing gloves or mittens

Large mechanical buttons

Homing bar

to help people with visual impairments

Homing bar

Tamper alarm

if someone attempts to detach the device

Tamper alarm
ip66

protection from dust, water, and harsh temperature

Jeweller radio communication

Jeweller radio communication

Power adjustment

protection from physical impact

Buzzer for sound notifications

about alarms, security mode changes, entry/exit delays, doors being opened (Chime), and other events

Buzzer for sound notifications

Holding screw

for reliable fastening

Holding screw
Remote control

Remote control and configuration

Optional 12 V⎓ external power supply

Informative push notifications

Ajax logo
10:00

Ajax

Home: Backyard armed by John

Ajax logo
10:00

Ajax

Office: Night Mode activated by Ann

Up to 5,550 ft

of communication range1 with an Ajax hub or range extender

Durable enclosure in three colors

Durable enclosure in three colors

Up to 2 years of operation

on pre-installed batteries

Pre-installed batteries

Hassle-free installation

1

QR code

2

SmartBracket

3

App

Compliance

Soft spacer on SmartBracket

for secure mounting on uneven surfaces

Device compatibility

In an Ajax system, you can combine devices of all product categories: Intrusion protection (both Superior and Baseline), Video surveillance, Fire and life safety, or Comfort and automation. Create the system to suit your needs and manage it in a single interface.

Ready to last in any setting

Energy infrastructure

Power station

Store

Store

Office

Office

Construction site

Construction site

Production facility

Factory

Private residence

Private residence

Remote site

Remote site

One device, three missions

With KeyPad Outdoor Jeweller, security management is always within reach. The keypad can control the entire facility or specific groups and supports Night mode. Additionally, the device can operate in bypass mode, activating an entry/exit delay before the system is disarmed using the main keypad.

Security management of the entire site or individual groups

Night mode support

Bypass mode

Security management

KeyPad Outdoor Jeweller offers convenient control of automation devices, including switches, relays, outlets, and shut-off valves. With a single press of the OK button, the system can automatically close garage doors or turn off outdoor lights upon arming — and restore them upon disarming. The backlit buttons indicate automation device status2: green for on, red for off.

Control of automation devices using the OK button

Backlight indication of automation device status

Automation device control

The keypad’s backlit digits remain clearly visible at all times. The built-in buzzer provides notifications of alarms, doors being opened (Chime), arming/disarming, and entry/exit delays. LED brightness and buzzer volume can be adjusted via Ajax apps.

Sound notifications for alarms and events

Mechanical buttons with backlit digits that are not fading off

Adjustable buzzer volume and LED brightness

Sound and LED indication

Fast and secure authentication

KeyPad Outdoor Jeweller supports multiple authentication methods — Pass and Tag access devices, smartphones, and codes — providing maximum convenience for any use case. All events, including user activity and authentication details, are logged and can be viewed in Ajax apps.

Pass card and Tag key fob

Pass and Tag are the perfect solution for contactless system control at sites with high in-and-out traffic. These devices eliminate the need to remember passcodes or repeatedly set up app accounts. Instead, construction workers, office staff, or cleaning personnel simply present a card or key fob to the keypad’s reader.

Pass card and Tag key fob

Smartphone

KeyPad Outdoor Jeweller supports authentication via smartphones thanks to the Bluetooth Low Energy (BLE) technology. If granted access rights, users can arm or disarm the system simply by bringing their smartphone near the keypad — no passcodes, no access devices, no hassle.

Smartphone

Passcode

KeyPad Outdoor Jeweller supports multiple types of access codes — general, for registered users, for unregistered users, and for rapid response units (RRU) — to meet a broad range of user- or site-specific needs.

Passcode

Contactless access devices

Both Pass cards and Tag key fobs feature original DESFire® chips and provide identical functionality in different form factors. A single access device can control up to 13 security systems. Pass and Tag devices are sold separately in batches of 3, 10, or 100 units.

Pass

Contactless card to control security modes

Pass

Tag

Contactless key fob to control security modes

Pass

Remote access control

Access rights and codes for KeyPad Outdoor Jeweller are easily managed via Ajax apps. Lost access devices or compromised codes can be handled remotely in just a few clicks — no need to visit the site.

Remote code management

Remote access rights management

Remote access device blocking

Remote access control

Access codes for unregistered users

KeyPad Outdoor Jeweller supports up to 99 codes for users without Ajax accounts, depending on a hub model. Configurable in the hub settings, these codes are ideal for granting access to verified temporary visitors, such as office staff or cleaning personnel.

Access codes

Notifications for adding, changing, or deleting codes

Unique name and ID assigned for user identification

Up to 99 codes for unregistered users

Ready to assist in emergencies

Emergency alert

The user triggers an emergency alert

Emergency alert

The system transmits the alarm

Emergency alert

The security company dispatches a rapid response unit

KeyPad Outdoor Jeweller features a configurable function button that can act as a panic button. When pressed, it sends an alarm alert to the monitoring station and system users via Ajax apps. The button can also trigger sirens and automation scenarios, such as activating a smoke machine to deter intruders.

The keypad also supports duress codes to enhance personal safety during emergencies. If a user is forced to disarm the system, entering a duress code simulates normal disarming, while discreetly alerting the monitoring station and other users to the situation.

Panic button for emergency alerts

Duress codes for silent alarms

Discover future-proof hardware

Durable enclosure

Durable enclosure with IP66 and IK08 protection

Ensures reliable performance in harsh conditions, such as rain, snow, or extreme heat

Large mechanical buttons

Large mechanical buttons with a homing bar

Enable quick and accurate use, even when the user is wearing gloves

LED backlight

LED backlight

Indicates the current security mode, automation devices status, and other keypad commands

DESFire and BLE reader

DESFire® and BLE reader

Supports authentication via Tag, Pass, and smartphone

Built-in buzzer

Built-in buzzer

Notifies of alarms, security mode changes, entry/exit delays, doors being opened (Chime), and other events

Pre-installed batteries

Pre-installed batteries

Provide autonomous operation for up to 2 years

Removable terminal board

Removable 12 V⎓ terminal board with cable channel

Simplifies the wiring process

SmartBracket mounting panel

SmartBracket mounting panel with fixing points and soft spacer

Helps easily install the keypad on any surface without disassembling the enclosure

Jeweller antenna

Jeweller antenna

Provides up to 5,550 ft of radio communication range

Two tamper buttons

Two tamper buttons

Trigger alerts if the keypad is detached from the surface or removed from the mounting panel

Holding screw

Holding screw

Secures the keypad on the mounting panel

Reliable performance

KeyPad Outdoor Jeweller runs on pre-installed CR123A batteries from trusted manufacturers. The batteries are tested in real time during production, and Ajax Systems inspects every unit to ensure it meets performance parameters. The batteries provide up to 2 years of autonomous operation and are easily replaceable. Battery status is always visible in Ajax apps with early low-battery notifications helping users and monitoring companies plan maintenance in advance.

The keypad also supports connection to a 12 V⎓ external power supply unit. In this case, the pre-installed batteries serve as a backup, keeping the device operational even during power outages.

Up to 2 years of operation on pre-installed batteries

Early low battery notifications

Support for a 12 V⎓ external power supply

Pre-installed batteries
Unique wireless technology

Jeweller

Unique wireless technology

Jeweller is Ajax’s proprietary radio protocol for secure two-way communication. It provides block encryption and device authentication during each communication session with an Ajax hub or radio signal range extender. Jeweller prevents sabotage, spoofing, and data theft.

Up to 5,550 ft of communication range in an open space

Data encryption

Notification of jamming and connection loss

Automatic power adjustment

Communication through steel and concrete

Some facilities have thick walls, metal partitions, or sheer distances that affect signal quality. Ajax range extenders are designed to increase the range of a wireless network and deliver stable connection with a hub despite the obstacles. And by choosing the model with an Ethernet cable connector, you get an additional communication channel. А single system can accommodate up to five range extenders.

Up to 5 range extenders within one system

Ethernet-equipped model available

Advanced system supervision

As part of the Ajax ecosystem, KeyPad Outdoor Jeweller is constantly supervised. The keypad performs automatic self-diagnosis and regularly reports key parameters to the hub. It maintains two-way communication with Ajax Cloud, which delivers data to Ajax apps. In the event of a malfunction or communication failure, the monitoring station is immediately notified to arrange necessary maintenance.

Automatic device self-diagnosis with state reporting

Customizable ping interval in the hub settings

Instant maintenance notifications

Advanced system supervision

Sabotage resistance

Tamper alarm

Tamper alarm

The keypad features two tamper buttons that trigger an alarm if someone attempts to detach the device from the surface or remove it from the mounting panel. For further sabotage protection, the keypad is also secured with a holding screw at the bottom of the enclosure.

Protection against code guessing

Protection against code guessing

After three unsuccessful code entry attempts or unverified access device uses, the keypad is blocked for a specified period. The system also immediately notifies users and the security company of the incident, effectively preventing unauthorized individuals from guessing the access code.

Protection against copying access devices

Protection against copying access devices

The keypad responds only to access devices authorized via Ajax apps. DESFire® chips in cards and key fobs comply with the ISO 14443 international standard and feature robust 128-bit encryption and copy protection. The BLE reader simply does not react to a smartphone unless it has been authorized via Ajax apps.

Durable enclosure

Durable enclosure

The keypad enclosure is IP66-rated and withstands temperatures from −13 °F to 140 °F. It performs reliably even in rain and snow. Non-fading mechanical buttons prevent wear patterns, making it impossible to identify commonly pressed digits and guess the code. The enclosure is rated IK08 for impact resistance and remains intact even under physical stress or direct hits.

Device authentication against spoofing

Device authentication against spoofing

The hub checks the device's unique parameters for authentication during each communication session. If any parameter fails the check, the hub ignores commands from the device.

Communication failure detection

Communication failure detection

The device regularly exchanges data with the hub. With the maximum ping interval settings (3 data packets every 12 seconds), it takes only 36 seconds to detect a communication loss and notify the security company and users about the incident.

Data encryption

Data encryption

All data stored and transmitted by the system is protected by a block cipher with a dynamic key. Encryption makes it extremely difficult to reprogram the device, as well as replace or steal data.

Informative push notifications

Informative push notifications

An Ajax system instantly notifies users and the monitoring company of alarms and events. Notifications clearly indicate which device was triggered, when and where it happened.

Regular polling

Regular polling

The keypad regularly exchanges data with the hub. The system monitors each device state and reports any malfunctions or connection losses.

Hassle-free installation and setup

Installing KeyPad Outdoor Jeweller is a breeze. With the SmartBracket mounting panel, there is no need to disassemble the enclosure — an installer can easily mount the device on the wall. The keypad is then added to the hub automatically by scanning the QR code. All configuration and testing can be done remotely via Ajax apps.

Adding to the hub via QR code

Connection

Effortless and secure installation with the SmartBracket mounting panel

Installation

Configuration and testing remotely or on-site

Setup

Monitoring via Ajax PRO Desktop or third-party monitoring software

Monitoring
1

In open space.

2

When the keypad runs a scenario involving multiple automation devices, the OK button cannot indicate the state of the device or scenario via LED. Instead, the keypad confirms the action with a short buzzer beep.
