Tech specs

DomeCam HLVF (8 Mp)

Wired AI-powered security IP camera with a 2.8–12 mm motorized varifocal lens, hybrid illumination, True WDR, audio and alarm inputs/outputs, microphone, and PoE/12 V. For outdoor and indoor use.

Device compatibility

Check

Camera

Image sensor

8 MP CMOS, 1/2.8" type

Lens focal length

2.8–12.0 mm

Maximum aperture

f/1.6

Lens iris type

fixed

Lens focal type

varifocal

Field of view

horizontal: 31°–111°

vertical: 17°–57°

diagonal: 35°–135°

Maximum illumination distance

white LED: up to 82 ft
IR LED: up to 131 ft

Intelligent lighting control automatically adjusts the intensity of IR and white LEDs in real time to prevent overexposure. This ensures clear visibility of objects at varying distances, both near and far, in low-light conditions.

Video

Resolution

8 MP (3840 × 2160)
6 MP (3072 × 1728)
5 MP (2944 × 1656)
5 MP (2880 × 1620)
5 MP (2688 × 1520)
5 MP (2592 × 1944)
4 MP (2560 × 1440)
3 MP (2304 × 1296)
2 MP (1920 × 1080)
0.6 MP (1024 × 576)

Frame rate

up to 25 fps

Image rotation

0°, 90°, 180°, 270°

Video codec

H.265, H.264

Dynamic range

True WDR

Storage

microSD

Ajax NVR

Camera supports microSD cards up to 256 GB. The memory card must be Class V30 or faster. The card is not included in the complete set.

Audio

Built-in microphones

With the corresponding settings applied, the camera can record audio at the scene.

Audio codec

G.711 µ-law, G.711 A-law, G.726, G.722

Intelligent video analytics

Motion detection

The camera detects motion using software-based image frame analysis.

AI object detection

People

Pets

Vehicles

Line-crossing

Network

Port

1 × RJ45 self-adaptive Ethernet (10/100 Mbps)

Protocol

HTTP, HTTPS, TCP/IP, IPv4, IPv6, SNMP, RTSP, UDP, DHCP, DNS, DDNS

Interoperability

ONVIF (Profile S/T*)

Ajax cameras and NVRs can be integrated into third-party video management systems (VMS).

* Profile T is supported for basic streaming and configuration. Advanced features such as metadata, event handling, or edge recording may not be available.

Learn more

Alarm port

Lines for third-party devices

Alarm IN type

NO, NC

Configured in Ajax apps.

Alarm IN max voltage

5 V⎓

Alarm OUT operating range

48 V⎓, 300 mA

Audio port

Lines for third-party devices

Audio IN type

external microphone input

Supports active microphones with a built-in preamplifier.

Audio IN settings

gain

enable/disable

Configured in Ajax apps.

Audio OUT type

speaker output

Supports connection of an external speaker (min. 3 W, ≥ 4 Ω). When an external speaker is connected, the internal one is disabled.

Key features

Video transmission

JetSparrow

Fast and encrypted peer-to-peer technology developed by Ajax Systems.

Focal length change

autofocus

manual focus control

Configured in Ajax apps.

Visual verification of system alarms

Ajax systems allow users to configure a scenario in which Ajax detectors trigger selected cameras to start recording. The recorded event is immediately delivered to the mobile or desktop Ajax PRO app.

Privacy

Advanced privacy controls ensure a high level of personal data protection. All access rights — including those for mobile app users, installers, and monitoring company operators using Ajax PRO Desktop — are fully configurable by the device owner. This guarantees that only authorized parties can access video streams, event history, and device settings in accordance with the owner's preferences.
