NVR DC (16-ch)

NVR models

16-channel

With up to 4K resolution (25/30 FPS).

IP cameras

• ONVIF (Profile S/T)
• RTSP

Storage

hard drive with a capacity of up to 16 TB (SATA connectivity, 3.5” size)

HDD is not included. A hard drive with power consumption of up to 7 W can be connected.

Decoding formats

H.265
H.264

Bandwidth

up to 100 Mbit/s

Ethernet

up to 100 Mbit/s

Bluetooth

BLE frequency band: 2.400–2.4835 GHz

To set up an Ethernet connection.

Radio signal power

2.5 mW (with the 100 mW limit)

Motion detection

NVR DC features built-in software to detect movement in the frame. It is possible to switch between image analysis by NVR DC or camera algorithms in an Ajax app.

In-app video management system

• Video wall that combines images from all connected cameras.
• Event filters.
• Timeline with smooth preview.

Visual verification of Ajax alarms

NVR DC allows for setting up a scenario in which Ajax detectors trigger specific cameras to start recording. The result is immediately delivered to mobile and desktop apps.

Support for ONVIF authorization

Profile S

Profile T (partially)

Ajax cameras and NVRs can be integrated into third-party video management systems (VMS).

Privacy

Access rights distribution for users in mobile apps and for monitoring company operators in PRO Desktop.

Without an installed jumper on the PSU board

• 8–16 V⎓, up to 4 A
• 8 V⎓ — turn-on threshold when the voltage rises
• 6.5 V⎓ — turn-off threshold when the voltage drops

With an installed jumper on the PSU board

• 12.1–16 V⎓, up to 4 A
• 12.1 V⎓ — turn-on threshold when the voltage rises
• 10.35 V⎓ — turn-off threshold when the voltage drops

Power consumption

up to 24 W

Clock battery

CR2032 battery, 3 V

Only to power the system clock.

Tamper alarm

Notifications of an attempt to detach the device from the surface or remove it from the mounting panel.

NVR DC

SmartBracket mounting panel

Terminal adapter

Ethernet cable

Installation kit

Quick start guide
