NVR HAC (16-ch)

Video input

16 channels

Recording resolution

12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

HDMI output resolution

1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720 px

Live view / playback resolution

8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p, D1, VGA, CIF

Format

H.265, H.264, JetSparrow

Capability

• 1 × channel at 12MP
• 1 × channel at 8MP
• 3 × channel at 5MP
• 4 × channel at 4MP
• 4 × channel at 1080p
• 10 × channel at 720p
• 16 × channel at 1024 × 576 px

The width or height of the camera video resolution (each channel) cannot exceed 4096 pixels.

Live view window division

templates: 1, 4, 9, 16, 5+1, 7+1 views

custom: up to 10×10 views

Synchronous playback

16 channels

Motion detection

Ajax camera: 16 channels

NVR: 16 channels

NVR HAC features built-in software to detect movement in the frame. It is possible to switch between image analysis by NVR HAC or camera algorithms in an Ajax app.

AI object detection

Ajax camera: 16 channels

HDD

1 × SATA: supports hard drive with up to 16 TB capacity (3.5” form factor)

HDD is not included.

Network

1 × RJ-45 self-adaptive Ethernet (10/100 Mbps)

USB

rear panel: 1 × USB 2.0 (Type-A)

side panel: 1 × USB 2.0 (Type-A)

To connect a keyboard, mouse, or a USB flash drive.

Bandwidth

incoming: up to 80 Mbps

outgoing: up to 40 Mbps

Protocol

HTTP, HTTPS, TCP/IP, IPv4, IPv6, SNMP, RTSP, UDP, DHCP, DNS, DDNS

Interoperability

ONVIF

Supported devices

• Ajax cameras
• IP cameras using ONVIF (Profile S/T) or RTSP

Built-in video management system

• Integrated video wall interface with live camera feeds.
• Smart event filters for quick access to relevant footage.
• Interactive timeline with preview navigation for efficient playback and incident review.

Visual verification of Ajax system alarms

NVR HAC supports a scenario in which events triggered by Ajax detectors automatically highlight the corresponding camera feed on the video wall. This allows for immediate intrusion verification by the operator.

Privacy

Advanced privacy controls ensure a high level of personal data protection. All access rights — including those for mobile app users, installers, and monitoring company operators via Ajax PRO Desktop — are fully configurable by the device owner. This guarantees that only authorized parties can access video streams, event history, or device settings, in accordance with the owner’s preferences.

Main

110–240 V, 50/60 Hz, 0.6 A

Power consumption

up to 24 W

Clock battery

CR2032 battery, 3 V

Only to power the system clock.

NVR HAC (16-ch)

SmartBracket mounting panel

Power cable

Ethernet cable

Installation kit

Quick start guide
