Socket (type G) Jeweller

Power supply voltage

230 V~, 50 Hz

Maximum continuous load current

13 A

Output power

up to 3 kW (resistive load at 230 V~)

Average consumption

up to 1.5 W

Current protection

1–16 A

Once the current exceeds the selected value, the plug turns off automatically. The recommended value is up to 13 A for permanent load and 13–16 A for short-term load.

Voltage protection

min — 184 V~
max — 253 V~

Once the voltage exceeds the specified levels, the plug turns off automatically.

Temperature protection

more than +203 °F

If protection is triggered, the plug turns off.

Electric shock protection class

Class I (with grounding terminal)

Jeweller communication technology

Proprietary wireless communication technology to transmit commands, alarms, and events.

Key features:

• Two-way communication.
• Advanced anti-sabotage.
• Block encryption featuring a dynamic key.
• Instant notifications.
• Remote control and configuration in Ajax apps.

Frequency bands

866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz

Depends on the sales region.

Maximum effective radiated power (ERP)

up to 20 mW

Radio signal modulation

GFSK

Radio communication range

up to 3,600 ft

Between the device and a hub (or a range extender) in an open space.

Encrypted communication

All stored and transmitted data are protected by block encryption featuring a dynamic key.

Frequency hopping

To prevent radio interference and jamming.

Control via smartphone

The user can set up the plug configurations and receive a detailed event log in the Ajax app.

Automation scenarios

• By arming/disarming
• By schedule
• By alarm
• By temperature
• By humidity*
• By CO₂ concentration*
• By touching LightSwitch / pressing Button

* Scenarios by humidity and CO₂ concentrations are available when LifeQuality Jeweller is added to the system.

Energy consumption monitor

Control of the current, voltage, power, and electric energy consumed by connected appliances. All data is saved to the non-volatile memory and can be reset in the Ajax app.

Adjustable pulse duration

from 1 to 255 s

LED indication

Informs about the plug’s state and the power consumption of connected appliances with different colors. The brightness of the LED frame can be adjusted or turned off in the Ajax app.

Operation modes

• pulse
• bistable

Contact state

• normally open
• normally closed

Childproofing

The plug is equipped with special internal shutters. They protect children by preventing them from inserting items like screwdrivers, scissors, or hairpins into the plug and also guard against dust and splashes.

Protection against spoofing

device authentication

Communication loss detection

after 36 s

Detection time depends on the Jeweller or Jeweller/Fibra settings.
