Takeover Module Jeweller

Data transfer protocols

Jeweller

To transmit commands, alarms, and events.

Wings

To transmit large data packets, such as firmware updates.

Frequency bands

905.0–926.5 MHz

Maximum effective radiated power (ERP)

up to 25 mW

Radio signal modulation

GFSK

Radio communication range

TBC

Between the device and a hub (or range extender) in open space. The maximum range depends on the hub model.

Calculate radio communication range at the facility

Encrypted communication

All stored and transmitted data is protected with advanced encryption, ensuring both confidentiality and integrity.

Frequency hopping

To prevent radio interference and jamming.

Number of devices

up to 80 wireless devices

Radio frequencies

319.5 MHz

345 MHz

433 MHz (coming soon)

Compatibility

Qolsys, Interlogix

Honeywell, Resideo, 2GIG

AT&T (coming soon)

DSC (coming soon)

The complete list of compatible devices is available in the integration module user manual.

Radio communication range

up to 650 ft

Between the third-party device and the integration module in open space. The maximum range depends on the third-party device specifications.

Device types

configurable device types with relevant settings

Adjusted by a PRO or a user with admin rights in an Ajax app.

Tamper alarm

The system sends notifications about attempts to detach the integration module from the surface or remove it from the mounting panel.

Protection against spoofing

To ensure authentication of the integration module when communicating with a hub.

Communication loss detection

after 36 seconds without a signal

The detection time depends on Jeweller or Jeweller/Fibra settings.

Main

12 V⎓, up to 1 A

Backup

built-in rechargeable Li-ion battery 1.8 Аh

Up to 24 hours of autonomous operation after loss of the main power supply.

Takeover Module Jeweller

SmartBracket mounting panel

Power adapter

Installation kit

Quick start guide
