Superior DoubleButton G3 Jeweller

Superior Jeweller data transfer protocol

Proprietary wireless protocol for transmitting commands, alarms, and events. An upgraded version of the Jeweller radio protocol for Superior devices, ensuring compliance with Grade 3 (EN 50131).

Key features:

• Two-way communication.
• Advanced sabotage protection.
• Enhanced block encryption with a dynamic key.
• Instant notifications.
• Remote configuration in the Ajax apps.

Frequency bands

865.0–868.0 MHz

868.0–868.6 MHz

868.7–869.2 MHz

869.4–869.65 MHz

Maximum effective radiated power (ERP)

up to 20 mW

Automatic power control to reduce power consumption and noise interference.

Radio signal modulation

GFSK

Radio signal range

up to 11,450 ft (TBC)

Between the hold-up device and control panel (or range extender) in an open space. The maximum range depends on the hub model. Locate Superior DoubleButton G3 Jeweller in a place with stable Jeweller signal strength (2-3 bars in the Ajax app).

Encrypted communication

All stored and transmitted data is protected with advanced encryption, ensuring both confidentiality and integrity.

Frequency hopping

Radio communication uses frequency hopping to prevent interception and jamming.

Number of buttons

2

Accidental press protection

both buttons pressing

protective plastic divider

Alarm confirmation

with one DoubleButton or several

To raise a confirmed alarm (hold-up event), you need to perform the selected action.

LED backlight indicating command delivery

The LED brightness is adjusted in Ajax apps.

Alarm scenario

by the DoubleButton pressing

The control mode for automation devices is not supported.

Protection against spoofing

device authentication

Battery

1 × CR2032

Pre-installed.

Calculated battery life

up to 6 years

Up to 4 years until Low Battery status.

Device’s operating voltage range

1.8−3.3 V⎓

Device’s nominal operating voltage

3 V⎓

Quiescent device’s current consumption at nominal voltage

0.54 μA

Maximum device’s current consumption at nominal voltage

34.8 mA

Full battery capacity

235 mAh

Low battery voltage

2.3 V⎓

Low battery recovery voltage

2.5 V⎓

End-of-life battery voltage

1.8 V⎓

Device is switched off.

End-of-life battery capacity

40 mAh

Manufacturer

Panasonic

Superior DoubleButton G3 Jeweller

CR2032 battery (pre-installed)

Quick start guide
