Fire Hub Lite Jeweller

FireProtect 2 SB series detectors

FireProtect 2 AC series detectors

Devices

up to 50

Users

1

Jeweller communication technology

Proprietary wireless communication technology to transmit commands, alarms, and other events.

Key features:

• Two-way communication
• Advanced sabotage protection
• Block encryption featuring a dynamic key
• Instant notifications
• Remote control and configuration in apps

Frequency bands

915.85–926.5 MHz

Depends on the sales region.

Maximum effective radiated power (ERP)

up to 20 mW

Automatic power control to reduce power consumption and radio interference.

Radio signal modulation

GFSK

Radio communication range

up to 4,900 ft

Between the control panel and connected devices in open space. Maximum range depends on the connected device.

Encrypted communication

All stored and transmitted data is protected by block encryption featuring a dynamic key.

Frequency hopping

To prevent radio interference and jamming.

Supported notification types

• push notifications

Event types

• Alarms
• Faults
• System events

Interconnected fire detector alarm

via primary interconnection

If one of the fire detectors in the system detects a fire, it sends an alarm to the control panel. Within 20 seconds, the control panel activates an interconnected fire alarm and sends information to apps.

via fallback interconnection

Along with sending an alarm to the control panel, the initiating detector transmits alarm information directly to other fire detectors. All connected detectors activate their buzzers within a minute. This works even in the worst-case scenario of losing connection with the control panel.

Device locking

When a compatible device is added to Fire Hub Lite Jeweller, its ID is verified automatically. If the device is already registered to another account, it cannot be added to the system.

LED indication

green, yellow, and red

An LED indicator on the control panel enclosure indicates the control panel state. Depending on the control panel operating mode, the indicator lights up or blinks in green, yellow, or red.

Tamper button

Notifications on attempts to detach the control panel from the surface.

Protection against spoofing

device authentication

Connection loss detection

after 36 s

Detection time depends on Jeweller settings.

Main

110–240 V, 50/60 Hz

Up to 50 mA of mains current consumption.

Backup

3 V⎓, 1.6 Ah

Up to five minutes of offline operation when Ethernet is switched off. A backup battery is not included in the complete set.

Fire Hub Lite Jeweller

Installation kit

Quick start guide
