ReX Jeweller

Number of ReX Jeweller connected to the hub

up to 5

Depends on the hub model.

Number of devices connected to ReX Jeweller

up to 199

Depends on the hub model.Only Hub 2 Plus Jeweller and Hub 2 (4G) Jeweller are under certification by UL.

Jeweller communication technology

Proprietary wireless communication technology to transmit commands, alarms, and events.

Key features:

• Two-way communication.
• Advanced anti-sabotage.
• Block encryption featuring a dynamic key.
• Instant notifications.
• Remote control and configuration in Ajax apps.

Frequency bands

866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz*
915.85–926.5 MHz
921.0–922.0 MHz

Depends on the sales region.

* Certified according to UL/ULC standards.

Maximum effective radiated power (ERP)

up to 25 mW

Automatic power control to reduce power consumption and radio interference.

Radio signal modulation

GFSK

Radio communication range

up to 5,900 ft

Between the range extender and a hub in an open space.

Encrypted communication

All stored and transmitted data are protected by block encryption featuring a dynamic key.

Frequency hopping

To prevent radio interference and jamming.

Alarm delivery time to the hub

0.3 s

Tamper alarm

Notifications on attempts to detach the device from the surface or remove it from the mounting panel.

Protection against spoofing

device authentication

Communication loss detection

after 36 s

Detection time depends on the Jeweller or Jeweller/Fibra settings.

Main

110–240 V, 50/60 Hz

Up to 6 W of mains power consumption.

Backup

built-in backup batteryRechargeable Li-ion Polymer Battery XK 953562T3.7 V⎓, 2 Ah

Calculated battery life:

• Up to 24 hours of backup battery life when Ethernet is disabled.

• Up to 35 hours of backup battery life.
• Up to 4 hours of maximum time to recharge a backup battery of maximum capacity to 80% of its rated capacity.

* From the backup battery after the loss of the main power supply.

The range extender manufactured after October 7, 2022, has a 3-pin battery. If the range extender was manufactured earlier, the battery can be a 2-pin or 3-pin one. To find out the battery type, contact Ajax Technical Support or check it manually.

Manufacturer
Dongguan Lean Power

UL listed.

Type

type A

Quiescent device’s current consumption at nominal voltage

11.4 mA

Maximum device’s current consumption at nominal voltage

14 mA

Low battery voltage

3.7 V⎓

Low battery recovery voltage

4.1 V⎓

End-of-life battery voltage

3.6 V⎓

Device is switched off.

Minimum energy level for a backup battery in the charged state

100%

Alternative

12 V⎓

Connected via an alternative power supply unit* 12V PSU for Hub/Hub Plus/ReX which is sold separately.

* Not evaluated by UL.

ReX Jeweller

SmartBracket mounting panel

Power cable

Installation kit

Quick start guide
